Turck Bi5-G18-An6X-0.2-Rs4T Inductive 4641593
Turck
$162.40
Manufacturer's Part Number: 4641593
Inductive Sensor. Ident. no.: 4641593. Threaded barrel, M18 x 1. Chrome-plated brass. DC 3-wire, 10
30 VDC. NO contact, NPN output. Pigtail with M12 Ã 1 connector
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 5 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, NPN
- Switching frequency:
- 0.50 kHz
- Electrical connection:
- Cable with connector, M12 ?ù 1
- Cable length (L):
- 0.20 m
- Housing material:
- Metal, CuZn, Chrome-plated
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
