Turck Bi5-G18K-Rn6X-0.2-Rsm40 Inductive 4671499
Turck
$161.10
Manufacturer's Part Number: 4671499
Inductive Sensor. Ident. no.: 4671499. M18 Ã 1 threaded barrel. Chrome-plated brass. DC 3-wire, 10
30 VDC. NC contact, NPN output. Pigtail with male end 7/8
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 5 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NC contact, NPN
- Switching frequency:
- 0.50 kHz
- Electrical connection:
- Cable with connector, 7/8
- Cable length (L):
- 0.20 m
- Housing material:
- Metal, CuZn, Chrome-plated
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
