Turck Bi50U-Q80-Vp4X2-B1141 Inductive 1562005
Turck
$325.90
Manufacturer's Part Number: 1562005
Inductive Sensor. With Extended Switching Distance. Ident. no.: 1562005. Rectangular, height 40 mm. Active face on top. Plastic, PBT GF30 V0. Factor 1 for all metals. Increased switching distance. Protection class IP68. Resistant to magnetic fields. DC 4-wire, 10
65 VDC. Changeover contact, PNP output. 7/8" male connector
- Design:
- Rectangular
- Construction size:
- 92 x 80 x 40 mm, Q80
- Rated switching distance:
- 50 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à65 VDC
- Output function:
- Complementary contact, PNP
- Switching frequency:
- 0.250 kHz
- Electrical connection:
- Connector, 7/8
- Housing material:
- Plastic, PBT-GF30-V0
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP68
- Special features:
- uprox+, Factor 1, Resistant to magnetic fields
- Catalog:
- View
- Datasheet:
- View
