Turck Bim-Em18M-Ap4X-H1141 Magnetic 1579933
Turck
$279.50
Manufacturer's Part Number: 1579933
Magnetic Field Sensor. Magnetic-inductive Proximity Sensor. Ident. no.: 1579933. Threaded barrel, M18 x 1. Stainless steel, 1.4301. Rated operating distance 90 mm with DMR31-15-5 magnet. DC 3 wire, 10
65 VDC. NO contact, PNP output. Male connector, M12 x 1
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 90 mm
- Operating voltage:
- 10?à65 VDC
- Output function:
- NO contact, PNP
- Electrical connection:
- Connector, M12 ?ù 1
- Housing material:
- Metal, 1.4301 (AISI 304)
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
- Special features:
- Magnetic-inductive
- Catalog:
- View
- Datasheet:
- View
