Turck Bl20-E-2Cnt-2Pwm System-Io 6827341

TURCK Bl20-E-2Cnt-2Pwm System-Io 6827341

Turck
SKU:
BL20-E-2CNT-2PWM
Availability:
Factory Stock: 36
$565.10
Condition:
New
Manufacturer's Part Number: 6827341
Current Stock:
Description
BL20 Economy Module. 2 × Counter/Encoder Channels, 2x PWM Outputs. Ident. no.: 6827341. Fieldbus-independent. Electronics and connection technology in one housing. Connectivity: Push-in terminals. Protection class IP20. LEDs indicate status and diagnostic. Electronics galvanically isolated from the field level via optocouplers. 2 x counter/encoder channels 200 kHz. 2 PWM outputs 20kHz / 0.5A. 2 digital outputs 20kHz / 0.5A. Counting mode: Continuous, single or periodic count. Measuring principle: Frequency, rotational speed or period duration measurement
Additional Information
Signal type:
Counter, Digital input, Digital output, PWM
Connection technology signal:
Cage clamp terminal
Device type:
I/O Module
Ambient temperature:
0?à+55 ??C
Protection class:
IP20
Approvals:
cULus
Manual:
View
Catalog:
View
Datasheet:
View
