Manufacturer's Part Number: U6419-0
Actuator and Sensor Field Wireable. 7/8 Connection. Ident. no.: U6419-0. 7/8 Male, Right-angle, 3-pin. Plastic Housing. Screw terminal Wire Termination
- Application:
- Signal
- Connector A:
- Male, 7/8-16 UN, Right angle
- Number of contacts:
- 3
- Connection mode:
- Screw/clamp connection
- Housing material:
- Plastic, PBT
- Coupling nut/screw material:
- Zinc-Aluminum, CuZn, Nickel-plated
- Acceptable cable diameter:
- 6?à8 mm
- Voltage:
- 600 V
- Current:
- 12 A
- Approvals:
- UL Recognized, RoHS
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
