Manufacturer's Part Number: U2-03909
Actuator and Sensor Field Wireable. 7/8 Connection. Ident. no.: U2-03909. Screw terminal Wire Termination. Plastic housing. 1 1/8 Male, Straight, 12-pin. Plastic Housing
- Application:
- Signal
- Connector A:
- Male, 1 1/8-16 UN, Straight
- Number of contacts:
- 12
- Connection mode:
- Screw/clamp connection
- Housing material:
- Plastic, PBT
- Coupling nut/screw material:
- Brass, CuZn, Nickel-plated
- Acceptable cable diameter:
- 13?à18 mm
- Voltage:
- 600 V
- Current:
- 7 A
