Turck Fci-D10A4P-2Arx-H1160/D201 Flow 6870679
Turck
$1,008.30
Manufacturer's Part Number: 6870679
Flow Monitoring. Inline Sensor with Integrated Processor. Relay Output 24 VDC NO. Ident. no.: 6870679. Flow sensor for liquid media. Calorimetric principle. Adjustment via potentiometer. LED band. Operating range 0.8
15 l/min. 2 relay switching outputs. Switching outputs 24 VDC NO. Switchpoints freely adjustable
- Function:
- Flow monitoring
- Design:
- Inline
- Process connection:
- 3/8'' Swagelok
- Medium:
- liquids
- Detection type:
- Calorimetric
- Operating voltage:
- 21.6?à26.4 VDC
- Output function:
- NO contact, Relay output
- Electrical connection:
- Connector, M12 ?ù 1
- Sensor material:
- Stainless steel
- Medium temperature:
- -10?à+95 ??C
- Ambient temperature:
- -20?à+60 ??C
- Protection class:
- IP65
- Flyer:
- View
- Datasheet:
- View
