Turck FCI-D10A4P-AP8X-H1141/A ID# 6870646
Turck
$639.00
Manufacturer's Part Number: 6870646
Flow Monitoring. Inline Sensor with Integrated Processor. Ident. no.: 6870646. Flow sensor for gaseous media. Calorimetric principle. Adjustment via potentiometer. LED band. Operating range 0.5
40 m/s. DC 3-wire, 19.2
28.8 VDC. NO contact, PNP output. Connector device, M12 Ã 1
- Function:
- Flow monitoring
- Design:
- Inline
- Process connection:
- G 1/4''
- Medium:
- gases
- Detection type:
- Calorimetric
- Operating voltage:
- 19.2 28.8 VDC
- Output function:
- NO contact, PNP
- Electrical connection:
- Connector, M12 × 1
- Sensor material:
- Stainless steel
- Housing material:
- Plastic, PBT
- Medium temperature:
- -20 +80 °C
- Ambient temperature:
- 0 +60 °C
- Protection class:
- IP67
- Approvals:
- UL
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
