Turck Fcs-M18-Ap8X/D087 Flow 6870800
Turck
$437.00
Manufacturer's Part Number: 6870800
Flow Monitoring. Immersion Sensor with Integrated Processor. Ident. no.: 6870800. Sensor for gaseous media. Calorimetric principle. Adjustments via potentiometer. Status display via 2-color LED. Chrome-plated brass sensor. 3 wire DC, 19.2
28.8 VDC. NO contact, PNP output. Cable device
- Function:
- Flow monitoring
- Design:
- Immersion
- Process connection:
- 1/4?ö NPT female thread
- Medium:
- gases
- Detection type:
- Calorimetric
- Operating voltage:
- 19.2?à28.8 VDC
- Output function:
- NO contact, PNP
- Electrical connection:
- Cable
- Cable length (L):
- 2.0 m
- Sensor material:
- Brass
- Housing material:
- Metal, CuZn
- Medium temperature:
- -20?à+70 ??C
- Ambient temperature:
- 0?à+60 ??C
- Protection class:
- IP67
- Approvals:
- UL
- Quick Start Guide:
- View
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
