Turck Fksdd Rj45Sf 44/St Receptacles U2-21428
Turck
$41.70
Panel Feed-through Receptacle. Female Receptacle to Female Receptacle. Rear Mount. Ident. no.: U2-21428. For Industrial Ethernet. RJ45 on M12 x 1, 4-pin. Admissible wall thickness: 1.5
3 mm. Mounting thread: M16 x 1, 8-pin. D-coding. Voltage: 42 V. RJ45, Female, Straight, 8-pin, Shielded
- Application:
- Data
- Design:
- Panel feedthrough
- Connector A:
- Female, M12 ?ù 1, Straight, D-code
- Number of contacts:
- 4
- Connector body:
- Die-cast Zinc, GD-Zn, nickel-plated, Black
- Mounting orientation:
- Rear mount
- Mounting thread:
- M16 ?ù 1.5
- Connector B:
- Female, RJ45, Straight
- Number of contacts:
- 8
- Fieldbus Protocol:
- Ethernet
- Voltage:
- 48 V
- Current:
- 0.2 A
- Protection class (When coupled):
- IP67
- Approvals:
- RoHS
