Turck FTCI-N3/4D19A4P-2ARX-H1160 ID# 6870053
Turck
$1,209.50
Manufacturer's Part Number: 6870053
Flow Rate Monitoring. Inline Sensor with Integrated Processor. Relay Output 24 VDC NO. Ident. no.: 6870053. Compact inline flow sensor. Calorimetric principle. Monitoring of flow rate. Monitoring of the medium temperature. For water/glycol mix. Parametrized via button. Protected by software code. Hysteresis flow 0.4
1.9 l/min. Hysteresis temp 1
10 °C. Temperature monitoring -10
95 °C. Switch-on/switch-off delay 0
50 s. 2 relay switching outputs. Switching outputs 24 VDC NO. Switchpoints freely adjustable
- Function:
- Flow rate measurement
- Design:
- Inline
- Process connection:
- 3/4 NPT
- Medium:
- liquids
- Detection type:
- Calorimetric
- Operating voltage:
- 21.6?à26.4 VDC
- Output function:
- NO contact, Relay output
- Electrical connection:
- Connector, M12 ?ù 1
- Sensor material:
- Stainless steel
- Housing material:
- Plastic, PBT
- Medium temperature:
- -10?à+95 ??C
- Ambient temperature:
- -20?à+60 ??C
- Protection class:
- IP54
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
