Turck Im1-12Ex-Mt Isolated Barriers 7541228
Turck
$473.80
Manufacturer's Part Number: 7541228
Isolating switching amplifier. 1-channel. Ident. no.: 7541228. 2 transistor outputs (MOSFET). Output mode adjustable (NO/NC mode). Input circuits monitored for wire-break and short-circuit. Complete galvanic isolation. Input reverse-polarity protected. ATEX, IECEx, cUL, cFM, CSA, TR CU, NEPSI, KOSHA, CCOE, INMETRO. Installation in zone 2
- Signal type:
- Digital input
- Device type:
- Isolating switching amplifier
- Ex version:
- yes
- Approvals:
- ATEX, IECEx, UL, cFMus, CSA, TR CU, NEPSI, KOSHA, TIIS, CCOE, INMETRO
- Nominal voltage:
- Wide voltage range
- Number of channels:
- 1
- Digital output:
- MOSFET output
- Electrical connection:
- 4 ?ù 3-pin removable terminal blocks, reverse polarity protected, screw terminal
- Protection class:
- IP20
- Product series:
- IM
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
