Turck

Turck Im12-Di01-2S-2R-0/24Vdc Isolated Barriers 7580036

(No reviews yet) Write a Review
SKU:
IM12-DI01-2S-2R-0/24VDC
Condition:
New
EAN:
4047101415520
eCl@ss-Code (V5.1.4)::
27210121 -/- Isolating switching amplifier
Customs tariff number:
85437090990
Country of origin:
DE
Weight:
164 g
Signal type:
Digital input
Device type:
Isolating switching amplifier
Ex version:
no
Approvals:
cULus
Functional safety (SIL/PL):
SIL2
Nominal voltage:
24 VDC
Number of channels:
2
Digital output:
Relay output
Electrical connection:
Removable screw terminals, 2-pin
Protection class:
IP20
Product series:
IM(X)12
$211.70

Description

Isolating switching amplifier, 2-channel, ATEX use in Zone 2, cUL, SIL 2, 2 relay outputs (complementary contact), Switchable: 2-channel or signal doubling, Output mode adjustable (NO/NC mode), Input circuits monitored for wire-break/short-circuit (ON/OFF switchable), Complete galvanic isolation, Input reverse-polarity protected, Removable screw terminals
