Manufacturer's Part Number: 7506444
Isolating transducer. 1-channel. Ident. no.: 7506444. Power supply of 2-wire measuring transducers with HART communication as well as connection to active 2-wire and passive 3-wire transmitters. Input circuit: 0/4
20 mA. Output circuit: 0/4
20 mA. Removable terminal blocks, screwable, with 2 mm test socket. Complete galvanic isolation. Input reverse-polarity protected. ATEX, IECEx, CFMUS, TR CU, INMETRO, NEPSI. Installation in zone 2
- Signal type:
- Analog input (HART transparent)
- Device type:
- Isolating transducer
- Ex version:
- yes
- Approvals:
- ATEX, IECEx, cFMus, TR CU, INMETRO
- Nominal voltage:
- Wide voltage range
- Number of channels:
- 1
- Electrical connection:
- 4 ?ù 5-pin removable terminal blocks with test socket, reverse polarity protected, screw terminal
- Protection class:
- IP20
- Product series:
- IM
