Turck Im33-14Ex-Cdri Isolated Barriers 7560015
Turck
$963.70
Manufacturer's Part Number: 7560015
Isolating transducer. 1-channel. Ident. no.: 7560015. Monitoring of analog values and ranges according to over and underrange. Line monitoring. Parameterized via PC (FDT/DTM), front-panel switch or HART. Ring buffer for up to 8000 measured values. Display. Power supply of 2 and 3-wire measuring transducers. Suited for active and passive signals. Output circuit: 0/4
20 mA, reversible. 3 relay outputs. Universal operating voltage. Complete galvanic isolation. Input reverse-polarity protected. ATEX, IECEx, TR CU, KOSHA. Installation in zone 2
- Signal type:
- Analog input (HART transparent)
- Device type:
- Trip amplifier
- Ex version:
- yes
- Approvals:
- ATEX, IECEx, TR CU
- Nominal voltage:
- Wide voltage range
- Number of channels:
- 1
- Digital output:
- Relay output
- Electrical connection:
- 4 × 5-pin removable terminal blocks, reverse polarity protected, screw terminal
- Protection class:
- IP20
- Product series:
- IM
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
