Turck LRS510-10-51-2UPN8-H1141 Radar Level Measurement Sensor with 0.350-10m Range and IO-Link Output
Turck
$1,345.00
Manufacturer's Part Number: 100012731
The Turck LRS510-10-51-2UPN8-H1141 Radar Level Measurement Sensor is designed for precise and reliable level measurement in various industrial applications. With a measuring range of 0.350 to 10 meters, this sensor ensures accurate detection of material levels. It features a G 3/4" process connection for easy installation and integration into existing systems. The sensor is equipped with 2 NPN/PNP switching outputs and 1 IO-Link output, providing versatile connectivity options for seamless communication with control systems. Ideal for use in challenging environments, this radar sensor offers robust performance and durability.
Product Features
Range: 10 m, Blind zone: 35 cm, Resolution: 1 mm, Cone angle of the radar beam: ±5°, Distance, level, volume or % output, Approved according to ETSI 305550-2, Approved according to FCC/CFR. 47 Part 15., Male connector, M12 × 1, 4-pin, Operating voltage 18 33 VDC, Switching output switchable between PNP/NPN, IO-Link, 4-digit, 2-colored, 14-segment display, Housing is rotatable by 180° after mounting the process connection, Process connection G3/4, Pressure resistance -1 16 bar rel., "
Product Features
Range: 10 m, Blind zone: 35 cm, Resolution: 1 mm, Cone angle of the radar beam: ±5°, Distance, level, volume or % output, Approved according to ETSI 305550-2, Approved according to FCC/CFR. 47 Part 15., Male connector, M12 × 1, 4-pin, Operating voltage 18 33 VDC, Switching output switchable between PNP/NPN, IO-Link, 4-digit, 2-colored, 14-segment display, Housing is rotatable by 180° after mounting the process connection, Process connection G3/4, Pressure resistance -1 16 bar rel., "
