Turck Ni20U-Em30-An6X-H1141 Inductive 1646350
Turck
$167.70
Manufacturer's Part Number: 1646350
Inductive Sensor. Ident. no.: 1646350. M30 1.5 threaded tube. Stainless steel, 1.4301. Factor 1 for all metals. Protection class IP68. Resistant to magnetic fields. Extended temperature range. High switching frequency. Auto-compensation protects against pre-damping. DC 3-wire, 1030 VDC. NO contact, NPN output. M12 x 1 male connector
- Design:
- Threaded barrel
- Construction size:
- M30 x 1.5
- Rated switching distance:
- 20 mm
- Mounting:
- Non-flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, NPN
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Connector, M12 ?ù 1
- Housing material:
- Stainless steel, 1.4301 (AISI 304)
- Ambient temperature:
- -30?à+85 ??C
- Protection class:
- IP68
- Special features:
- uprox+, Factor 1, Resistant to magnetic fields
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
