Turck Ni20U-Gt30-Ap6X-B1141/S332 Inductive 1646248
Turck
$284.20
Manufacturer's Part Number: 1646248
Inductive Sensor. Ident. no.: 1646248. Threaded barrel, M30 x 1.5. Brass, PTFE-coated. Factor 1 for all metals. Protection class IP68. Resistant to magnetic fields. Extended temperature range. High switching frequency. DC 3-wire, 10
30 VDC. NO contact, PNP output. 7/8" male connector
- Design:
- Threaded barrel
- Construction size:
- M30 x 1.5
- Rated switching distance:
- 20 mm
- Mounting:
- Non-flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, PNP
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Connector, 7/8
- Housing material:
- Metal, CuZn, PTFE-coated
- Ambient temperature:
- -30?à+85 ??C
- Protection class:
- IP68
- Special features:
- uprox+, Factor 1, Resistant to magnetic fields, PTFE-coated
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
