Turck

Turck Ni3-Eg08K-Ap6X-0.2-Psg3M Inductive 4669610

(No reviews yet) Write a Review
SKU:
NI3-EG08K-AP6X-0.2-PSG3M
MPN:
4669610
Condition:
New
Design:
Threaded barrel
Construction size:
M8 x 1
Rated switching distance:
3 mm
Mounting:
Non-flush
Operating voltage:
10…30 VDC
Output function:
NO contact, PNP
Switching frequency:
3.0 kHz
Electrical connection:
Cable with connector, M8 × 1
Cable length (L):
0.20 m
Housing material:
Stainless steel, 1.4305 (AISI 303)
Ambient temperature:
-25…+70 °C
Protection class:
IP67
Catalog:
View
Datasheet:
View
  • Turck Ni3-Eg08K-Ap6X-0.2-Psg3M Inductive 4669610
  • Turck Ni3-Eg08K-Ap6X-0.2-Psg3M Inductive Sensor, Standard
$160.40

Description

Inductive Sensor. Ident. no.: 4669610. Threaded barrel, M8 1. Stainless steel, 1.4305 (AISI 303). DC 3-wire, 1030 VDC. NO contact, PNP output. Pigtail with male end M8 x 1
