Turck Ni4-Eg08-Ag41X-H1341 Inductive 4561001
Turck
$152.90
Manufacturer's Part Number: 4561001
Inductive Sensor. With Increased Switching Distance. Ident. no.: 4561001. Threaded barrel, M8 x 1. Stainless steel, 1.4427 SO. Large sensing range. DC 2-wire, 10
55 VDC. Polarized version. NO contact. M12 x 1 male connector
- Design:
- Threaded barrel
- Construction size:
- M8 x 1
- Rated switching distance:
- 4 mm
- Mounting:
- Non-flush
- Operating voltage:
- 10?à55 VDC
- Output function:
- NO contact, 2-wire
- Switching frequency:
- 0.30 kHz
- Electrical connection:
- Connector, M12 ?ù 1
- Housing material:
- Stainless steel, 1.4427 SO
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
- Special features:
- Sn +
- Catalog:
- View
- Datasheet:
- View
