Turck Pkg 3Z-8-Psg 3/S760/S771/S1579 Cordsets UX17693
Turck
$51.00
Manufacturer's Part Number: UX17693
Actuator and Sensor Cordset. Extension Cordset. Ident. no.: UX17693. Straight Female M8 picofast Connector. Straight Male M8 picofast Connector. M8, Female, Straight, 3-pin. Snap-on Connector with Sleeve Lock. M8, Male, Straight, 3-pin. Snap-on Connector. General Purpose Cable. Black PVC jacket, 3X24 AWG. -40 Cold Bend Rating. Flame Ratings: UL1061, CSA FT1. Flexlife® and C-Track Approved
- Application:
- Signal
- Design:
- Double-ended
- Connector A:
- Female, M8 - ?ÿ 8 mm (snap), Straight
- Coupling nut:
- Plastic, POM, Black
- Connector B:
- Male, M8 - ?ÿ 8 mm (snap), Straight
- Voltage:
- 125 V
- Current:
- 4 A
- Cable diameter:
- ?ÿ 4.19 mm
- Length (L):
- 8.0 m
- Cable jacket:
- PVC, Black
- Number of Conductors:
- 3
- Protection class (When coupled):
- IP67
- Approvals:
- CSA C22.2 No. 182.3, CE, RoHS, UL Listed, UL 2238
- Flyer:
- View
- Catalog:
- View
