Turck

Turck Pkg 6Z-10/S760 Cordsets U-44516

(No reviews yet) Write a Review
SKU:
PKG 6Z-10/S760
MPN:
U-44516
Condition:
New
Application:
Signal
Design:
Single-ended
Connector A:
Female, M8 - ?ÿ 8 mm (snap), Straight
Number of contacts:
6
Connector body:
Plastic, TPU, Yellow
Voltage:
125 V
Current:
2 A
Cable diameter:
?ÿ 4.5 mm
Length (L):
10.0 m
Cable jacket:
PVC, Black
Number of Conductors:
6
Protection class (When coupled):
IP67
Approvals:
UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
Flyer:
View
Catalog:
View
Datasheet:
View
  • Turck Pkg 6Z-10/S760 Cordsets U-44516
  • Turck Pkg 6Z-10/S760 Single-ended Cordset, Straight Female Connector
$62.70

Description

Actuator and Sensor Cable. Connection Cable. Ident. no.: U-44516. M8, Female, Straight, 6-pin. Snap-on Connector with Sleeve Lock. General Purpose Cable. Black PVC jacket, 6X26 AWG. -40 Cold Bend Rating. Flame Ratings: UL1061, CSA FT1
