Turck PT1000R-2004-IOL-H1141 ID# 100017813
Turck
$211.60
Manufacturer's Part Number: 100017813
Pressure Transmitter. IO-Link with Two Switching Outputs. Ident. no.: 100017813. Fully welded metal measuring cell. Pressure range 0
1000 bar rel.. 18
33 V DC. NO/NC contact, 2 Ã PNP/NPN outputs, IO-Link. Process connection G1/4 male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring. Connector device, M12 Ã 1
- Design:
- Without display
- Process connection:
- G1/4 male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0 1000 bar
- Pressure range psi:
- 0 14504 psi
- Operating voltage:
- 18 33 VDC
- Electrical output:
- 2 × switching output
- Communication protocol:
- IO-Link
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Stainless steel 1.4435 (AISI 316L)
- Medium temperature:
- -40 +135 °C
- Ambient temperature:
- -30 +85 °C
- Protection class:
- IP67
- Approvals:
- CE, Metrological certification (RUS), cULus
- Manual:
- View
- Quick Start Guide:
- View
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
