Turck Pt150Psig-1005-I2-H1143 Pressure 6837488
Turck
$169.30
Manufacturer's Part Number: 6837488
Pressure Transmitter. With Current Output (2-Wire). Ident. no.: 6837488. Ceramic measuring cell. Compact and robust design. Excellent EMC properties. Pressure range 0
150 psi relative. 7
33 VDC. Analog output 4
20 mA. Process connection 7/16" UNF (SAE) male thread. Plug-in device, M12 Ã 1
- Design:
- Without display
- Process connection:
- 7/16-20 UNF male thread
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0 10.34 bar
- Pressure range psi:
- 0 150 psi
- Operating voltage:
- 7 33 VDC
- Electrical output:
- Current output (2-wire)
- Current output:
- 4 20 mA
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Ceramic AlO
- Medium temperature:
- -40 +125 °C
- Ambient temperature:
- -30 +85 °C
- Protection class:
- IP67
- Approvals:
- CE, Metrological certification (RUS), cULus
- Quick Start Guide:
- View
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
