Turck

Turck Pt16R-2004-I2-H1141 Pressure 6836392

SKU:

PT16R-2004-I2-H1141

UPC:

MPN:

Condition:

New

EAN:

4047101397918

eCl@ss-Code (V5.1.4)::

27200614 -/- Piezoresistive sensor (absolute and relative pressure)

Customs tariff number:

90262020000

Country of origin:

CH

Weight:

95 g

Design:

Without display

Process connection:

G1/4? male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring

Pressure type:

Relative pressure

Pressure range bar:

0…16 bar

Pressure range psi:

0…232.06 psi

Operating voltage:

7…33 VDC

Electrical output:

Current output (2-wire)

Current output:

4…20 mA

Electrical connection:

Connector, M12 × 1

Housing material:

Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0

Pressure transducer material:

Stainless steel 1.4016 (AISI 430)

Medium temperature:

-40…+135 °C

Ambient temperature:

-30…+85 °C

Protection class:

IP67

Approvals:

CE, Metrological certification (RUS), cULus
