Turck Pt3000Psig-2003-U1-H1143 Pressure 6837292
Turck
$194.70
Manufacturer's Part Number: 6837292
Pressure Transmitter. With Voltage Output (3-Wire). Ident. no.: 6837292. Fully welded metal measuring cell. Pressure range 0
3000 psi rel.. 12
33 VDC. Analog output 0
10 V. Process connection 1/4"-18 NPT male thread. Plug-in device, M12 Ã 1
- Design:
- Without display
- Process connection:
- 1/4 NPT-18 male thread
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0 206.84 bar
- Pressure range psi:
- 0 3000 psi
- Operating voltage:
- 12 33 VDC
- Electrical output:
- Voltage output (3-wire)
- Voltage output:
- 0 10 V
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Stainless steel 1.4435 (AISI 316L)
- Medium temperature:
- -40 +135 °C
- Ambient temperature:
- -30 +85 °C
- Protection class:
- IP67
- Approvals:
- CE, Metrological certification (RUS), cULus
