Turck Pt3000Psig-2121-I2-Dt043P Pressure 100002007
Turck
$169.30
Manufacturer's Part Number: 100002007
Pressure Transmitter. With Current Output (2-Wire). Ident. no.: 100002007. For mobile hydraulic applications. Fully welded metal measuring cell. Sealless. With pressure tip orifice. Compact and robust design. Excellent EMC properties. Excellent accuracy and long-term stability. Kfz-Norm ISO 16750. Pressure range 0
3000 psi rel.. 7.5
33 VDC. Analog output 4
20 mA. Process connection 9/16"-18 UNF (SAE) male thread. Plug-in device, Deutsch DT04-3P
- Design:
- Without display
- Process connection:
- 9/16-18 UNF male thread
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0 206.84 bar
- Pressure range psi:
- 0 3000 psi
- Operating voltage:
- 7.5 33 VDC
- Electrical output:
- Current output (2-wire)
- Current output:
- 4 20 mA
- Electrical connection:
- Connector, Deutsch DT04-3P
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Stainless steel 1.4404 (AISI 316L)
- Medium temperature:
- -40 +125 °C
- Ambient temperature:
- -40 +100 °C
- Protection class:
- IP69K
- Quick Start Guide:
- View
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
