Manufacturer's Part Number: 100033123
Pressure Transmitter. With Current Output (2-Wire). Ident. no.: 100033123. Ceramic measuring cell. Compact and robust design. Excellent EMC properties. Pressure range 0
4 bar rel.. 7
33 VDC. Analog output 4
20 mA. Process connection 1/4"-18 NPT male thread. Plug-in device, M12 Ã 1
- Design:
- Without display
- Process connection:
- 1/4 NPT-18 male thread
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0?à4 bar
- Pressure range psi:
- 0?à58.02 psi
- Operating voltage:
- 7?à33 VDC
- Electrical output:
- Current output (2-wire)
- Current output:
- 4?à20 mA
- Electrical connection:
- Connector, M12 ?ù 1
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Ceramic AlO
- Medium temperature:
- -40?à+125 ??C
- Ambient temperature:
- -30?à+85 ??C
- Protection class:
- IP67
- Approvals:
- CE, Metrological certification (RUS), cULus
