Turck Pt5000Psig-2005-Ix-H1143/X Pressure 100022577
Pressure Transmitter. With Current Output (2-Wire). Ident. no.: 100022577. Fully welded metal measuring cell. Pressure range 0
5000 psi rel.. Pressure peak orifice. 10
30 VDC. Analog output 4
20 mA. Process connection 7/16" UNF (SAE) male thread. Plug-in device, M12 Ã 1. ATEX, IECEx. Category II 1/2 GD, Ex zone 0
- Design:
- Without display
- Process connection:
- 7/16-20 UNF male thread
- Pressure type:
- Relative pressure
- Pressure range bar:
- 0 344.74 bar
- Pressure range psi:
- 0 5000 psi
- Operating voltage:
- 10 30 VDC
- Electrical output:
- Current output (2-wire)
- Current output:
- 4 20 mA
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Material pressure transducer:
- Stainless steel 1.4435 (AISI 316L)
- Medium temperature:
- -30 +120 °C
- Ambient temperature:
- -25 +85 °C
- Protection class:
- IP67
- Approvals:
- ATEX II 1/2 GD, CE, IECEx II 1/2 GD, UKEX, GOST/EAC RU, Metrological certification (RUS), cULus
