Turck Rem-190Sa0C-Iol32B-H1141 Encoder 100018238
Turck
$756.50
(No reviews yet)
Write a Review
Write a Review
Turck
Turck Rem-190Sa0C-Iol32B-H1141 Encoder 100018238
Manufacturer's Part Number: 100018238
Absolute Rotary Encoder - Multiturn. IO-Link. Industrial Line. Ident. no.: 100018238. Clamping flange, à 36 mm. Solid shaft, à 6.35mm à 12.5mm. Magnetic measuring principle. Shaft material: stainless steel. IP67 rated on the shaft side. 40
+85 °C. Max. 4000 rev/min. 18
.30 VDC. M12 x 1 male connection, 4-pin. Singleturn resolution 14 bit scalable, default 14 bit. Multiturn resolution scalable only to 18 bits over total resolution, default 18 bits. Total resolution 32 bit scalable, default 32 bit
- Encoder line:
- Industrial-Line
- Technology:
- Magnetic
- Output type:
- Absolute multiturn
- Shaft Type:
- Solid shaft
- Shaft diameter D (mm):
- 6.35
- Flange diameter:
- ?ÿ 36 mm
- Flange type:
- Clamping flange
- Operating voltage:
- 18?à30 VDC
- Communication protocol:
- IO-Link
- Electrical connection:
- Connector, M12 ?ù 1
- Housing material:
- Die-cast zinc
- Ambient temperature:
- -40?à+85 ??C
- Protection class shaft:
- IP67
- Protection class:
- IP67
- Manual:
- View
- Catalog:
- View
- Datasheet:
- View
