Turck Rkc 6T-2/S618 Cordsets U5311-51
Turck
$38.10
Manufacturer's Part Number: U5311-51
Actuator and Sensor Cable. Connection Cable. Ident. no.: U5311-51. M12, Female, Straight, 6-pin. General Purpose Cable. Gray PVC jacket, shielded, 6X24 AWG. -40 Cold Bend Rating. Flame Ratings: UL1061, CSA FT1
- Application:
- Signal
- Design:
- Single-ended
- Connector A:
- Female, M12 ?ù 1, Straight, A-code
- Number of contacts:
- 6
- Connector body:
- Plastic, TPU
- Coupling nut:
- Brass, CuZn, Nickel-plated
- Current:
- 2 A
- Cable diameter:
- ?ÿ 5.13 mm
- Length (L):
- 2.0 m
- Cable jacket:
- PVC, Gray
- Number of Conductors:
- 6
- Protection class (When coupled):
- IP68, IP69K
- Special Features:
- Shielded
- Approvals:
- UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
