Turck Rm-109Sa0C-9D38B-H1151 Encoder 1545888
Turck
$1,281.80
Manufacturer's Part Number: 1545888
Absolute Rotary Encoder - Multiturn. Industrial Line. Ident. no.: 1545888. Ã 42 mm clamping flange. Solid shaft, Ã 1/4" x 1/2". Optical measuring principle. Shaft material, stainless steel. Protection class IP69K on the shaft side. 40
+85°C. max. 4000 rev/min. 10-30 VDC. CANopen DS 406 V4.0. M12 connection, 5-pin
- Encoder line:
- Industrial-Line
- Technology:
- Optical
- Output type:
- Absolute multiturn
- Shaft Type:
- Solid shaft
- Shaft diameter D:
- 0.25 in
- Flange diameter:
- Ø 42 mm
- Flange type:
- Clamping flange
- Operating voltage:
- 10 30 VDC
- Communication protocol:
- CANopen
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Die-cast zinc
- Ambient temperature:
- -40 +85 °C
- Protection class shaft:
- IP69K
- Manual:
- View
- Catalog:
- View
