Turck RM-28TA1R-3C24B-H1181/N16 ID# 200005120
Turck
$1,348.40
Manufacturer's Part Number: 200005120
Absolute Shaft Encoder. Industrial Line. Ident. no.: 200005120. Absolute Shaft Encoder. Protection class IP65 on shaft side. -40
+85 °C. Max. 12000 rpm (continuous operation 10000). 10
30 VDC. SSI, gray. M12 connector, 8-pin. Singleturn, 12-bit resolution. Multiturn, 12-bit resolution
- Encoder line:
- Industrial-Line
- Technology:
- Optical
- Output type:
- Absolute multiturn
- Shaft Type:
- Solid shaft
- Shaft diameter D (mm):
- 9.525
- Flange diameter:
- Ø 63.5 mm
- Flange type:
- Synchro flange
- Operating voltage:
- 10 30 VDC
- Communication protocol:
- SSi
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Die-cast zinc
- Ambient temperature:
- -40 +85 °C
- Protection class housing:
- IP67
- Protection class shaft:
- IP65
- Catalog:
- View
- Datasheet:
- View
