Turck Rsm Rkm 106-20M Cordsets U2-00508
Turck
$445.60
Manufacturer's Part Number: U2-00508
Actuator and Sensor Cable. Extension Cable. Ident. no.: U2-00508. 1-1/8 Male, Straight, 10-pin. 1-1/8 Female, Straight, 10-pin. Instrumentation Tray Cable. Yellow PVC jacket, 10X16 AWG. Sunlight Resistant. -40 Cold Bend Rating. Oil Resistant. Flame Ratings: UL 1685 FT4, UL1061, CSA FT4
- Application:
- Signal
- Design:
- Double-ended
- Connector A:
- Male, 1 1/8-16 UN, Straight
- Connector B:
- Female, 1 1/8-16 UN, Straight
- Voltage:
- 600 V
- Current:
- 7 A
- Cable diameter:
- 1.99 mm
- Length (L):
- 20.0 m
- Cable jacket:
- PVC, Yellow
- Number of Conductors:
- 10
- Protection class (When coupled):
- IP67, IP68, IP69, IP69K
- Special Features:
- Tray cable
- Approvals:
- UL 2238, CE, RoHS
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
