Turck Sdpb-0404D-0002 Fieldbus Accessories 6824113
Turck
$712.40
Manufacturer's Part Number: 6824113
piconet stand-alone module for PROFIBUS-DP. 4 Digital PNP Inputs Filter 0.2 ms. 4 Digital Outputs 0.5 A . Ident. no.: 6824113. Configuration interface. Parameterizable functions. Supported via I/O ASSISTANT 2. Direct connection to the fieldbus. Fibre-glass reinforced housing. Shock and vibration tested. Encapsulated module electronics. Metal connector. Degree of protection IP67
- Fieldbus Protocol:
- PROFIBUS-DP
- Signal type:
- Digital output, Digital input, Digital input/output
- Connection technology signal:
- M12
- Device type:
- I/O Module, Compact station
- Fieldbus transmission rate:
- 9.6 kbps ?à12 Mbps
- Fieldbus connection technology:
- 1 2
- Ambient temperature:
- 0?à+55 ??C
- Protection class:
- IP67
- Approvals:
- cULus
- Manual:
- View
- Flyer:
- View
- Datasheet:
- View
