Manufacturer's Part Number: U3-00775
Industrial Ethernet. Managed Switch. Ident. no.: U3-00775. 10/100 Mbps. Auto-sensing, 10/100M, half/full duplex, auto-negotiating. Auto cross-over, auto-polarity. Automatic address learning, aging and migration. Store and forward wire-speed switching. IEEE 802.3, 802.3u, 802.3x, 802.3D/w, 802.3p, 802.3Q. Real-Time-Ring or Rapid Spanning Tree (RSTP). SNMPv1 and v2 network management. SNMPv3 authentication & encryption for security. SNMP notifications. IGMP for multicast filtering (snooping and querying). Broadcast and multicast storm protection. RMON and port mirroring. Security with HTTPS, SSL, SSH, SNMPv3. Easy configuration via web. 8 ports + 1 RS232 configuration port. Ethernet connection: 4-pole, M12 D-coded. Power supply: 5-pole, 7/8. Protection class: IP67
- Device type:
- Ethernet switch
- Fieldbus connection technology:
- M12 ?ù 1 female connector, 4-pin, D-coded
- Transmission rate Ethernet:
- 10/100 Mbps
- Number of Ethernet ports:
- 8 ports (managed) + 1 RS232 config. port
- Connection technology Ethernet:
- 8 2, 4-pin, D-coded
- Ambient temperature:
- -40?à+75 ??C
- Protection class:
- IP67
