Turck Senl-0404D-0002 Fieldbus Accessories 6824481
Turck
$827.80
Manufacturer's Part Number: 6824481
piconet Coupling Module for Modbus TCP. 4 Digital PNP Inputs Filter 3 ms. 4 Digital Outputs 0.5 A . Ident. no.: 6824481. Configuration interface. Configurable functions. Supported via I/O ASSISTANT 2. Direct connection to the fieldbus. Direct connection to the IP link. Fibre-glass reinforced housing. Encapsulated module electronics. Metal connector. Degree of protection IP67
- Fieldbus Protocol:
- Modbus TCP
- Signal type:
- Digital output, Digital input, Digital input/output
- Connection technology signal:
- M12
- Device type:
- Coupler, Gateway
- Fieldbus connection technology:
- 1 × M12
- Transmission rate Ethernet:
- 10/100 Mbps
- Connection technology Ethernet:
- 1 × M12
- Ambient temperature:
- 0 +55 °C
- Protection class:
- IP67
- Approvals:
- cULus
- Manual:
- View
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
