Turck TB-EM30WD-H1147-EX ID# 7030385
Turck
$542.80
Manufacturer's Part Number: 7030385
HF Read/Write Head. For Explosion Hazardous Areas or Areas with Extreme Requirements (e.g. Food Industry). Ident. no.: 7030385. M30 × 1.5 threaded tube. Stainless steel 1.4404. Front cap made of liquid crystal polymer. High protection class IP69K for harsh environments. Special double-lip seal. Protection against all common acidic and alkaline cleaning agents. Suitable for applications in the food industry. Laser-engraved label, permanently legible. Powered and operated only via connection to BL ident interface module. M12 × 1 connector, connection only via BL ident extension cable. ATEX category II 3 G, Ex zone 2. ATEX category II 3 D, Ex zone 22
- Technology:
- HF RFID
- Radio communication and protocol standards:
- ISO 15693, NFC Typ 5
- Design:
- Threaded barrel
- Construction size:
- M30 x 1.5
- Read/Write distance max.:
- 45 mm
- Mounting:
- Flush
- Fieldbus Protocol:
- Connection to RFID interface
- Housing material:
- Stainless steel, 1.4404 (AISI 316L)
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP68/IP69K
- Approvals:
- ATEX II 3 G, ATEX II 3 D
- Manual:
- View
- Quick Start Guide:
- View
