Turck Tps-206A-Cf-H1141-L150 Temperature 9910639
Turck
$141.70
Manufacturer's Part Number: 9910639
Temperature Detection. Probe, Stainless Steel. Ident. no.: 9910639. Pt 100 probe acc. to DIN EN 60751. Vibration an shock-resistant. Class A for temperatures < 350 °C. Class B for temperatures > 350 °C. Can be connected to TS, TTM, IM34, BL20, BL67 and excom. Max. temperature connector: 120°C. Connection mode: 4-wire connection. Process connection via compression fitting or thermowell.
- Detection type:
- medium contact
- Design:
- Temperature probe
- Measuring range:
- -50 500 °C
- Immersion depth L:
- 150 mm
- Process connection:
- For compression fittings, thermowell or direct mounting
- Electrical output:
- Resistance
- Measuring element:
- Pt100
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Stainless steel, 1.4404 (AISI 316L)
- Ambient temperature:
- -40 +120 °C
- Protection class:
- IP67
