Turck

Turck Ws46Pt-S-0 Field Wireable Connectors U2-31188

(No reviews yet) Write a Review
SKU:
WS46PT-S-0
Condition:
New
Availability:
Factory Stock: 37
Application:
Power (>11 Amps)
Connector A:
Male, M12 × 1, Right angle, T-code
Number of contacts:
4
Connection mode:
Screw/clamp connection
Housing material:
Plastic, PA
Coupling nut/screw material:
Zinc, GD-Zn, Nickel-plated
Acceptable cable diameter:
8…10 mm
Core cross-section/Clamping ability:
16 mm²
Voltage:
63 V
Current:
12 A
Flyer:
View
Catalog:
View
Datasheet:
View
  • Turck Ws46Pt-S-0 Field Wireable Connectors U2-31188
  • Turck Ws46Pt-S-0 M12 Power, Field-Wireable Connector, Male Connector, M12ÿÿ1, Angled
$30.30

Description

Power Field Wireable. M12 Power. Male Connector M12 × 1, Angled. Ident. no.: U2-31188. Right angle Male M12 powerfast Field Wireable. 4 pins. Screw termination. Plastic housing. Screw-clamp terminal. 4-pin. Cable feedthrough: 8.0…10.0 mm. Terminal capacity: Max. 1.5 mm² or 16 AWG (with cable end sleeve). Max. 2.5 mm² or 14 AWG (without cable end sleeve)
