SMC VFS4100-5FZB 4/5 Port Solenoid Valve
- SKU:
- VFS4100-5FZB
- Condition:
- New
- Function:
- 1 (2 Position Single)
- Body Option:
- 0 (Base Mounted Plug-in)
- Direct Manual Override:
- 0 (Standard)
- Pilot:
- Internal Pilot
- Voltage:
- 5 (24VDC)
- Lead Wire:
- F (Plug-in)
- Surge Suppressor:
- Z (Light & Surge Suppressor)
- Manual Override:
- B (Locking Slotted Style)
- Piping:
- Side Ported (Or None in Case of w/o Subplate)
- Port Size:
- w/o Sub-plate
- Thread:
- Rc (Or None in Case of w/o Subplate)
Description
series vfs consists of 5 port pilot solenoid valves with metal seals and base mounted or body ported type manifolds. base mounted manifolds are available in plug-in and non plug-in styles. body ported manifolds are available with bar or separate type manifold bases. port sizes range from 1/8 to 3/4 with rc(pt), nptf and g(pf) thread types available. various options also available.
- fluid: air and inert gas
- operating pressure: 0.1mpa to 1.0mpa
- effective area (cv): 1.7 to 3.6
- coil rated voltage: 100, 200 vac 50/60hz; 24vdc
- response time: 55 or less ms
- ambient/fluid temp: -10 to 60 c
