WAGO 2000-5457
Wago
$21.26
TOPJOBS sensor terminal block; 2-pole; with ground connection on control panel side; rail mount; 4-conductor; 7 mm wide; orange.
The Sensr. suppl. terminal block from WAGO's 2000 TOPJOB S series is an orange, quadruple-deck terminal block with ground contact and side/lateral and center marking slots, designed for PNP (high-side) switching sensors. It accommodates 4 conductors and 9 wires with push-in connections, supporting a nominal cross-section of 1mm² and wire sizes ranging from 0.14mm² to 1.5mm² (#24AWG to #16AWG). Rated for a current of 28A, it features Push-in CAGE CLAMP spring connections and mounts on a DIN-35 rail with a width of 7mm, equivalent to model 20005457.
- actuation type:
- Push-in || Operating tool
- approvals per:
- UL 1059
- color:
- Orange
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 49.4 mm / 1.945 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.14 1.5 mm / 24 16 AWG
- fine stranded conductor 2:
- 0.25 4 mm / 22 12 AWG
- fine stranded conductor with ferrule push in termination:
- 0.5 0.75 mm / 20 18 AWG
- fine stranded conductor with insulated ferrule:
- 0.14 0.75 mm / 24 18 AWG
- fire load:
- 0.353 MJ
- flammability class per ul94:
- V0
- height:
- 97.3 mm / 3.831 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 1 mm
- nominal voltage iii 3:
- 250 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- rated current:
- 28 A
- rated current csa use group c:
- 20 A
- rated current ul use group b:
- 20 A
- rated current ul use group d:
- 20 A
- rated voltage csa use group c:
- 300 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60947-7-1
- solid conductor:
- 0.14 1.5 mm / 24 16 AWG
- solid conductor 2:
- 0.25 4 mm / 22 12 AWG
- solid conductor push in termination:
- 0.5 1.5 mm / 20 16 AWG
- solid conductor push in termination 2:
- 0.25 4 mm / 22 12 AWG
- strip length:
- 9 11 mm / 0.35 0.43 inch
- weight:
- 22.895 g
- width:
- 7 mm / 0.276 inch
- wiring direction:
- Front-entry wiring
