Wago 2001-1308

WAGO 2001-1308 3-conductor shield terminal block; 1.5 mm²; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP; 1,50 mm²; white

Wago
SKU:
60298129
$6.46
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
Shield terminal block; rail mount; 3-conductor; 4.2 mm wide; white.

The WAGO 2001 TOPJOB S series shield terminal block is a white, 1-deck/level component with side/lateral and center marking slots. It features a single shield-through pole (1S) and accommodates three wires (1 push-in + 2 push-in) with a nominal cross-section of 1.5mm², suitable for wire sizes ranging from 0.25mm² to 2.5mm² or #22AWG to #14AWG. The terminal block uses Push-in CAGE CLAMP spring connections and is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) with a width of 4.2mm, equivalent to model number 20011308.

Additional Information
actuation type:
Push-in || Operating tool
color:
White
connectable conductor materials:
Copper
connection technology:
Push-in CAGE CLAMP
country of origin sales organisation germany:
DE
depth from upper edge of din rail:
32.9 mm / 1.295 inch
design:
Horizontal type
fine stranded conductor:
0.25 2.5 mm / 22 14 AWG
fine stranded conductor with ferrule push in termination:
0.75 1.5 mm / 18 16 AWG
fine stranded conductor with insulated ferrule:
0.25 1.5 mm / 22 16 AWG
fire load:
0.000 MJ
flammability class per ul94:
V0
height:
59.2 mm / 2.33 inch
insulation material:
Polyamide (PA66)
marking level:
Center/side marking
mounting type:
DIN-35 rail
nominal cross section:
1.5 mm
note conductor cross section:
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
packaging type:
Box
ratings per:
IEC/EN 60947-7-2
solid conductor:
0.25 2.5 mm / 22 14 AWG
solid conductor push in termination:
0.75 2.5 mm / 18 14 AWG
strip length:
9 11 mm / 0.35 0.43 inch
weight:
7.958 g
width:
4.2 mm / 0.165 inch
wiring direction:
Front-entry wiring
