| Description | Push-in type jumper bar; insulated; 7-way; Nominal current 18 A | ||||||||||||||||||||||||||||||||
| Remarks | |||||||||||||||||||||||||||||||||
| Item properties | Miscellaneous
| ||||||||||||||||||||||||||||||||
The insulated push-in type comb-style jumper bar from WAGO's 2001 TOPJOB S series is a 7-way, 7-pole (7P) connector with a rated current of 18A. It is light gray in color and is equivalent to the model number 2001407.
- color:
- Light gray
- country of origin sales organisation germany:
- DE
- depth:
- 19 mm / 0.748 inch
- fire load:
- 0.021 MJ
- height:
- 4.1 mm / 0.161 inch
- jumper assignment:
- 7-way
- nominal voltage iii 3:
- 800 V
- packaging type:
- Bag
- rated current:
- 18 A
- rated current ex e ii:
- 16 A
- weight:
- 2.565 g
- width:
- 28.1 mm / 1.106 inch
