Wago 2002-2211/1000-411

WAGO 2002-2211/1000-411 Component Terminal Block with Diode

Wago
SKU:
2002-2211/1000-411
Availability:
Factory stock
$13.27
Condition:
New
Current Stock:
Description
Description Double-deck diode terminal block; with diode 1N4007
Remarks

Item properties

Miscellaneous

Name Value Unit
Total number of connection points  4
Total number of potentials  2
Color  gray
Ratings per  IEC/EN 60947-7-1
Rated current [A]  0.5  A
Nominal voltage [V]  250  V
Reverse voltage [V]  1000  V
Number of levels  2
Connection technology  Push-in CAGE CLAMP
Number of connection points connector  4
Actuation type  Operating tool
Connectable conductor materials  Copper
Nominal cross section  2.5 mm nbsp;
Solid conductor  0.25 4 mm / 22 12 AWG
Solid conductor, push-in termination  0.75 4 mm / 18 12 AWG
Fine-stranded conductor  0.25 4 mm / 22 12 AWG
Fine-stranded conductor with ferrule, push-in termination fr  0.75 mm / 18 AWG
Strip length  10 12 mm / 0.39 0.47 Inch
Type of wiring  Front-entry wiring
Design  horizontal
Marking level  Center/side marking
Insulating material  Polyamide 66 (PA 66)
Fire load [MJ]  0.219  MJ
Weight [g]  10.3  g
Width  5.2 mm / 0.205 Inch
Height from upper-edge of DIN-35 rail  51.7 mm / 2.035 Inch
Depth  69.7 mm / 2.744 Inch
Type of mounting  DIN-35 x 15 carrier rail
.

The WAGO 2002 TOPJOB S series component feed-through terminal block is a double-deck terminal block with a built-in diode (1N4007) and features side and center marking slots. It is gray in color and designed for two feed-through poles, accommodating four wires (two push-in connections on each level). The terminal block supports a nominal cross-section of 2.5mm² and is suitable for wire sizes ranging from 0.25mm² to 4mm² (#22AWG to #12AWG). It has a rated current of 0.5A and utilizes Push-in CAGE CLAMP spring connections. The terminal block is mounted on a DIN-35 rail and has a width of 5.2mm, equivalent to model number 200222111000411.

Additional Information
actuation type:
Push-in || Operating tool
color:
Gray
connectable conductor materials:
Copper
connection technology:
Push-in CAGE CLAMP
country of origin sales organisation germany:
DE
depth from upper edge of din rail:
51.7 mm / 2.035 inch
design:
Horizontal type
fine stranded conductor:
0.25 4 mm / 22 12 AWG
fine stranded conductor with ferrule push in termination:
1 2.5 mm / 18 14 AWG
fine stranded conductor with insulated ferrule:
0.25 2.5 mm / 22 14 AWG
fire load:
0.219 MJ
flammability class per ul94:
V0
height:
69.7 mm / 2.744 inch
insulation material:
Polyamide (PA66)
marking level:
Center/side marking
mounting type:
DIN-35 rail
nominal cross section:
2.5 mm
note conductor cross section:
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
packaging type:
Box
rated current:
0.5 A
ratings per:
IEC/EN 60947-7-1
solid conductor:
0.25 4 mm / 22 12 AWG
solid conductor push in termination:
0.75 4 mm / 18 12 AWG
strip length:
10 12 mm / 0.39 0.47 inch
weight:
10.300 g
width:
5.2 mm / 0.205 inch
wiring direction:
Front-entry wiring
