TOPJOBS triple-deck terminal block; internally commoned; rail mount; 6-conductor; 5.2 mm wide; gray.
The WAGO 2002 TOPJOB S series feed-through terminal block is a triple-deck unit with internal commoning and side/center marking slots, suitable for Ex e II applications. It features an "L" marking, is gray in color, and has one feed-through pole accommodating three push-in connections on each of its three levels, supporting wire sizes from 0.25mm² to 4mm² (#22AWG to #12AWG). The terminal block is rated for currents of 24A and 28A, utilizes Push-in CAGE CLAMP spring connections, and mounts on a DIN-35 rail with a width of 5.2mm, equivalent to model 20023208.
- color:
- Gray
- country of origin sales organisation germany:
- DE
- depth:
- 32.9 mm / 1.295 inch
- fire load:
- 0.073 MJ
- flammability class per ul94:
- V0
- height:
- 87.5 mm / 3.445 inch
- packaging type:
- Box
- weight:
- 2.440 g
- width:
- 1 mm / 0.039 inch
