WAGO 2003-7649 Terminal Block, 4-Way, Push-In, 32A, 400V, 2.5mm², Gray
Wago
$4.87
Multilevel installation terminal block; with operating slots; 2.5 mm²; N/L; Push-in CAGE CLAMP; 2,50 mm²; gray.
The WAGO 2003 TOPJOB S series terminal block is a multilevel, double-deck installation feed-through and neutral-through terminal block with side and center marking slots, marked "N/L." It features one feed-through pole and one neutral-through pole, accommodating two push-in connections per pole, suitable for wire sizes ranging from 0.25mm² to 4mm² or #22AWG to #12AWG. The terminal block supports a nominal cross-section of 2.5mm² and is rated for currents of 24A and 32A. It utilizes Push-in CAGE CLAMP spring connections and is designed for DIN-35 rail mounting with a width of 5.2mm, equivalent to model 20037649. The color of the terminal block is gray.
- actuation type:
- Push-in || Operating tool
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 42.3 mm / 1.665 inch
- design:
- Angled
- fine stranded conductor:
- 0.25 4 mm / 22 12 AWG
- fine stranded conductor with ferrule push in termination:
- 1 2.5 mm / 18 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm / 22 14 AWG
- fire load:
- 0.240 MJ
- flammability class per ul94:
- V0
- height:
- 96 mm / 3.78 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 2.5 mm
- nominal voltage iii 3:
- 400 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- rated current:
- 24 A
- rated current 2:
- 32 A
- rated surge voltage iii 3:
- 6 kV
- solid conductor:
- 0.25 4 mm / 22 12 AWG
- solid conductor push in termination:
- 0.75 4 mm / 18 12 AWG
- strip length:
- 10 12 mm / 0.39 0.47 inch
- weight:
- 13.608 g
- width:
- 5.2 mm / 0.205 inch
- wiring direction:
- Front-entry wiring
