WAGO 2006-1203 2-conductor through terminal block, 6 mm², red
Wago
$3.40
(No reviews yet)
Write a Review
Write a Review
Wago
WAGO 2006-1203 2-conductor through terminal block, 6 mm², red
2-conductor through terminal block, 6 mm², red.
The WAGO 2006 TOPJOB S series feed-through terminal block is a red, single-deck component with side and center marking slots, designed for Ex e II applications. It features one feed-through pole accommodating two wires via push-in connections, suitable for wire sizes ranging from 0.5mm² to 10mm² or #20AWG to #8AWG, with a nominal cross-section of 6mm². The terminal block supports rated currents of 41A and 57A, utilizes Push-in CAGE CLAMP spring connections, and mounts on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5mm, and a width of 7.5mm. It is equivalent to model 20061203.
- actuation type:
- Push-in || Operating tool
- approvals per:
- CSA 22.2 No 158
- color:
- Red
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP®
- CONTINUOUS OPERATING TEMPERATURE:
- -60 ¢¦ +105 °C
- COUNTRY OF ORIGIN VKORG GERMANY:
- DE
- CUSTOMS TARIFF NUMBER VKORG GERMANY:
- 85369010000
- DEPTH FROM UPPER EDGE OF DIN RAIL:
- 32.9 mm / 1.295 inches
- FINE STRANDED CONDUCTOR:
- 0.5 ¢¦ 10 mm² / 20 ¢¦ 8 AWG
- FINE STRANDED CONDUCTOR WITH FERRULE PUSH IN TERMINATION:
- 2.5 ¢¦ 6 mm² / 16 ¢¦ 10 AWG
- FINE STRANDED CONDUCTOR WITH INSULATED FERRULE:
- 0.5 ¢¦ 6 mm² / 20 ¢¦ 10 AWG
- FIRE LOAD:
- 0.011 MJ
- FLAMMABILITY CLASS PER UL94:
- V0
- HEIGHT:
- 57.4 mm / 2.26 inches
- INSULATION MATERIAL:
- Polyamide (PA66)
- LEGEND RATINGS:
- (III / 3) ¢ Overvoltage category III / Pollution degree 3
- MARKING LEVEL:
- Center/side marking
- MATERIAL GROUP:
- I
- MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
- MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
- MISMATING PROTECTION:
- MOUNTING NOTE=
- MOUNTING TYPE:
- DIN-35 rail
- NOMINAL CROSS SECTION:
- 6 mm²
- NOMINAL VOLTAGE III 3:
- 800 V
- NOTE CONDUCTOR CROSS SECTION:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- NOTE MATERIAL DATA:
- Information on material data can be found here
- POWER LOSS MAX PL MAX NOTE:
- 1.3112 W
- PROCESS DATA WIDTH:
- -35 ¢¦ +85 °C
- PROCESSOR:
- 22
- RATED CONTINUOUS THERMAL CURRENT ICTH:
- 41 A
- RATED CURRENT:
- 57 A
- RATED CURRENT 4:
- 50 A
- RATED CURRENT CSA USE GROUP B:
- 50 A
- RATED CURRENT CSA USE GROUP D:
- 38 A
- RATED CURRENT EX E II:
- 33 A
- RATED CURRENT EX E II WITH JUMPER:
- 41 A
- RATED CURRENT UL 1977:
- 50 A
- RATED CURRENT UL USE GROUP B FACTORY WIRING ONLY:
- 50 A
- RATED IMPULSE VOLTAGE III 2:
- 8 kV
- RATED VOLTAGE:
- 600 V
- RATED VOLTAGE CSA USE GROUP B:
- 600 V
- RATED VOLTAGE CSA USE GROUP D:
- 550 V
- RATED VOLTAGE UL 1977:
- 600 V
- RATED VOLTAGE UL USE GROUP B:
- 600 V
- RATINGS NOTE 4:
- IEC/EN 60947-7-1
- REFERENCE FOR MEASUREMENT ERROR 2:
- See installation notes in section ¢Knowledge¢ andDownloads ¢ Documentation ¢ Additional Information: Technical Section
- RESISTANCE TO SHOCK AND VIBRATION:
- 0.00078 ©
- SOLDER PIN LENGTH:
- 0.5 ¢¦ 10 mm² / 20 ¢¦ 8 AWG
- SOLID CONDUCTOR 4:
- 2.5 ¢¦ 10 mm² / 14 ¢¦ 8 AWG
- STRANDED CONDUCTOR 2:
- 13 ¢¦ 15 mm / 0.51 ¢¦ 0.59 inches
- WAGO SHIELD CLAMPING SADDLE:
- 8.893 g
- WEIGHT OF INSULATION MATERIAL:
- 7.5 mm / 0.295 inches
- WIRE LENGTH OF WIRE JUMPERS:
- Front-entry wiring
