WAGO 2010-1201 Terminal Block, 2 Positions, 20-6 AWG, 57A, DIN Rail Mount
Wago
$4.54
TOPJOBS feedthrough terminal block; rail mount; 2-conductor; 10 mm wide; gray.
The WAGO 2010 TOPJOB S series feed-through terminal block is a gray, single-deck unit with side and center marking slots, designed for Ex e II applications. It features one feed-through pole accommodating two wires via push-in connections, with a nominal cross-section of 10mm², suitable for wire sizes ranging from 0.5mm² to 16mm² or #20AWG to #6AWG. The terminal block supports rated currents of 57A and 76A and utilizes Push-in CAGE CLAMP spring connections. It is mounted on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5 and has a width of 10mm, equivalent to model 20101201.
- color:
- Gray
- conformity marking:
- CE
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- US
- depth:
- 91 mm / 3.583 inch
- depth from upper edge of din rail:
- 56 mm / 2.205 inch
- efficiency typ:
- 0.85
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.455 MJ
- height:
- 91 mm / 3.583 inch
- height from upper edge of din rail:
- 56 mm / 2.205 inch
- input voltage range:
- DC 15 30 V
- internal fuse:
- TVS diode
- load regulation:
- ¤ 0.7 %
- mains failure hold up time:
- 0.5 ms
- mounting type:
- DIN-35 rail
- nominal input voltage ui nom:
- DC 24 V
- nominal mains frequency range:
- 0 Hz
- nominal output current io nom:
- 0.5 A
- nominal output voltage uo nom:
- DC 10 V
- number of jumper slots:
- 2
- operating voltage feedthrough:
- ¤ 0.5 %
- output voltage range:
- 2 %
- overload behavior:
- Temporary no damage (short circuit of the output for 1 minute)
- packaging type:
- Box
- pollution degree:
- 2
- protection class:
- III
- protection type:
- IP20 (per EN 60529)
- residual ripple:
- ¤ 20 mV
- reverse voltage protection:
- Yes
- series operation:
- No
- signaling:
- 1 x LED
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 5 6 mm / 0.2 0.24 inch
- surrounding air temperature operation:
- -25 55 C
- switching frequency:
- 20 kHz (Nominal)
- wago connector:
- WAGO 859 Series
- weight:
- 41.100 g
- width:
- 6 mm / 0.236 inch
